Bianchi METHANOL CV RS 9.2– XTR 1X12SP

THE ULTIMATE HARDTAIL

METHANOL CV COMES READY TO TEAR UP THE CIRCUIT. IT HAS YEARS OF INNOVATION AND ITERATION BEHIND IT AND SUPER-EFFICIENT RACE GEOMETRY. IT’S A BIKE FOR THE RIDER WHO WANTS TO SMASH PERSONAL BESTS; THE ULTIMATE HARDTAIL



AFTER SHOCK CONTROL

Engineered with Bianchi CV System, using Countervail®’s unique carbon fiber architecture and viscoelastic resin, Methanol CV RS delivers total “After-Shock Control” by eliminating vibrations that pass through the suspension after impact and from trail buzz. “After-Shock Control” delivers an entirely new level of ride quality, with increased accuracy, reduced muscular fatigue and total performance.



COUNTERVAIL

The key technology Countervail® is a carbon composite-material system that combines patented structural carbon with viscoelastic resin.



BIANCHI CV INTEGRATED VIBRATION CANCELLING SYSTEM



Bianchi collaborated with Materials Sciences Corporation to develop our innovative and exclusive use of the MSC’s patented Countervail® integrated vibration cancelling system for cycling.

Countervail® is a carbon composite-material system that, with special fiber architecture, combines patented structural carbon with viscoelastic resin. Countervail® cancels 80% of vibrations while increasing the stiffness and strength of our carbon frames and forks.

Countervail® is embedded within the entire frame of Bianchi CV high-performance road and MTB models: Specialissima, Oltre XR4, Oltre XR3, Infinito CV, Aquila CV and Methanol CV.

PROVEN IN NASA AEROSPACE OPERATIONS

Traditional passive damping in frames using superficial rubber inserts and isolators are marginally effective compared to the integrated carbon Countervail® system developed by Bianchi for cycling and proven in the extreme conditions of NASA aerospace operations.



FRAME

Methanol CV RS has been engineered to be the best XCO and XCM racing machine, without compromises.

The new frame shape and structure saves weight, improves steering response and accuracy.

Frame’s weight in size 43 is 940gr.



NEW GEOMETRY

Geometry has been optimized to respond to the new faster, rougher race tracks by adding a longer reach and a slacker head tube angle. This creates a more confident feel for the rider at speed and a greater ability to attack the trail, especially in corners and steep descents.



DRIVETRAIN

The Methanol CV RS is now 1x drivetrain specific.



CLEARANCE

Improved clearance in the chainstays allows to accomodate larger tyres up to 58mm width in wet, muddy conditions.



MAKE IT SPECIAL WITH TAVOLOZZA

TAILOR-MADE PROGRAM

Bianchi Tavolozza is the exclusive web color configurator available for Bianchi CV models engineered with Countervail® vibration cancelling technology. All frames personalized with Tavolozza color configurator, including graphics and logos, are hand-painted and decaled in Italy by expert craftsmen, combining Bianchi’s timeless skills of tailoring together with advanced technologies.







BIKE TECH SPECS

COLOR

2A - CK16/BLACK GLOSSY OR TAVOLOZZA



SIZES

380 430 480 530



FRAME

METHANOL CV RS 29" CARBON HM MONOCOQUE W/COUNTERVAIL, 1.5" TAPERED HT, PRESSFIT BB92 (41X92MM), 1X DRIVETRAIN ONLY, 27,2MM SEATPOST, PM 160MM CARBON DROPOUT 12X148MM BOOST, INTERNAL CABLE ROUTING DI2 COMPATIBLE, SIZES 15,17,19,21"



FORK

FOX 32 SC 29" FACTORY KASHIMA REMOTE, 100MM TRAVEL



HEADSET

FSA ORBIT C-40



SHIFTERS

SHIMANO XTR SL-M9100IR 1X12SP



REAR DERAILLEUR

SHIMANO XTR RD-M9100 SGS 12SP



CRANKSET

SHIMANO XTR FC-M9100-1 34T, HOLLOWTECH II, CRANK LENGHT: 170MM-15", 175MM-17/21"



BB

SHIMANO SM-BB94-41A



CHAIN

SHIMANO CN-M9100, 12SP



SPROCKET

SHIMANO CS-M9100-12, 10-12-14-16-18-21-24-28-33-39-45-51T



BRAKES

SHIMANO XTR M9100



WHEELS

DT SWISS XR1501 SPLINE 29" 25MM



TIRE

KENDA BOOSTER PRO 29X2.20



STEM

FSA SL-K 3D FORGED/CNC AL2014 W/UD CARBON FACEPLATE, +/-12º, 1.1/8", DIAM. 31,8MM, EXT: 70MM-15", 80MM-17'', 90MM-19/21"



HANDLEBAR

FSA SL-K FLAT AL6066 W/CARBON WRAP, WIDTH 700MM, DIAM. 31.8MM, BACKSWEEP 9°, UPSWEEP 4°



GRIPS

T-ONE T-GP43X



SEATPOST

SL-K SB0, UD CARBON SHAFT W/ALLOY MTC HEAD. DIAM. 27,2MM, 0MM SEATBACK, LENGTH: 350MM-15", 400MM-17/21"



SADDLE

FI'ZI:K TAIGA



ROTOR

SHIMANO RT-MT900 DIAM. FRONT 180MM AND REAR 160MM



PEDALS

INCLUDED



WATERBOTTLE

ELITE CORSA 550ML, TEAM REPLICA



WATERBOTTLE HANGER

ELITE PARON COMPOSIT
