SOAR LIKE AN EAGLE
IN THE FIGHT FOR THE WIN SECONDS COUNT, AND WITH THE AQUILA YOU ALWAYS HAVE TIME ON YOUR SIDE. IT’S PROBABLY THE FASTEST TT BIKE IN THE WORLD
EVERY MILLISECOND MATTERS
We work closely with some of the world’s best time triallists helping to fine-tune their fit and position on the bike. From national championships to team time trials to general classification-winning individual triumphs – these victories don’t come by chance.
SUPER AERO HANDLEBAR
Aquila CV features full NACA (National Advisory Committee for Aeronautics) airfoil shape of the handlebar (designed by Bianchi).
Three different stem lengths: 90mm for sizes XS/SM, 110mm for size MD and 130mm for size LG.
Bianchi engineered a customized front tube cover, to smoothly hide the V-brake system. The rear V-brake is positioned in the bottom-bracket area to minimize the aerodynamic drag.
DOUBLE POSITIONING SEATPOST
TT and triathlon configuration with +/- 18mm setback.
ENGINEERED WITH BIANCHI CV SYSTEM
Oltre is engineered with the Bianchi CV System to cancel the road vibration. The result is in a smooth ride and a racer who can stay focused in his fastest, most efficient aerodynamic position for longer.
Bianchi CV system cancels 80% of road vibration thanks to the use of a unique composite material integrated in Bianchi’s high-performance carbon frames and forks. The Bianchi CV vibration cancelling system combines viscoelastic material together with a special carbon fiber architecture to dissipate vibration.
Advantages for the rider are more control, less muscle fatigue and more energy.
TESTED IN EVERY RACE SITUATIONS
Traditional passive damping in frames using superficial rubber inserts and isolators are marginally effective compared to the integrated vibration cancelling system developed by Bianchi for cycling and proven in the extreme conditions.
MAKE IT SPECIAL WITH TAVOLOZZA
Bianchi Tavolozza is the exclusive web color configurator available for Bianchi CV models engineered with Countervail® vibration cancelling technology. All frames personalized with Tavolozza color configurator, including graphics and logos, are hand-painted and decaled in Italy by expert craftsmen, combining Bianchi’s timeless skills of tailoring together with advanced technologies.
BIKE TECH SPECS
1D - CK16/BLACK GLOSSY OR TAVOLOZZA
XS SM MD LG
AQUILA CV CARBON W/COUNTERVAIL, MECHANICAL/ELECTRONIC SHIFTING COMPATIBLE, PRESSFIT 86,5X41MM, W/CARBON COVER, SIZE XS-SM-MD-LG
BIANCHI FULL CARBON W/COUNTERVAIL, 1.1/8", WITH PIVOT V-BRAKE, BLADES STRAIGHT WITH BRAKE COVERED
FSA NO.8-R, 1.1/8"
SHIMANO DURA ACE SL-BSR1 2X11SP, BAR END TYPE
SHIMANO ULTEGRA RD-R8000 SS 11SP
SHIMANO ULTEGRA FD-R8000
SHIMANO ULTEGRA FC-R8000 52X36T, HOLLOWTECH II, CRANK LENGTH: 165MM-XS, 170MM-SM, 172.5MM-MD, 175MM-LG
SHIMANO ULTEGRA CN-HG701-11, 11SP
SHIMANO ULTEGRA CS-R8000, 11-12-13-14-15-17-19-21-23-25-28T
FOURIERS AERO-860-BI, ALLOY FORGED AND CNC ALUMINUM ARMS
SHIMANO DURA ACE BL-TT79 FOR TT/TRIATHLON
FULCRUM RACING 418
VITTORIA RUBINO PRO G+ ISOTECH GRAPHENE 700X25
INCLUDED IN THE HANDLEBAR
BIANCHI AERO CARBON FULLY INTEGRATED FLAT CUSTOM HANDLEBAR AND STEM, WIDTH 41MM, STEM LENGTH 90MM-XS/SM, 110MM-MD, 130MM-LG, TOP CAP INCLUDED, DI2/EPS COMPATIBLE, W/FSA BAR ENDS LENGTH 260MM
BLACK SOFT MICROFIBER TAPES W/SHOCKPROOF EVA-139
BIANCHI AERO CARBON CUSTOM SHAPE WITH ALLOY HEAD ADJUSTABLE AND REVERSIBLE +/- 18MM, LENGTH: 300MM-XS/SM, 350MM-MD/LG
FI'ZI:K MISTICA MG
