Nukeproof Mega 290 Comp (2021)

Since 2009 the Nukeproof Mega has been on a constant development to meet the demands of our riders and customers alike.

To optimise the strength and weight, the Mega is contructed fully out of T6061-T6 Aluminium including all forged part.

After winning 4 Enduro World Series Titles in 3 years the all new design is an evolution of our ultimate Enduro bike. At the heart of the frame is all new suspension Kinematics, designed to be more subtle off the top, whilst remaining progressive and predictable . Anti-Squat is used to create an effective pedalling bike that can be thrashed through technical terrain. The useable SAG range is also widened to allow riders to tune the suspension to the trails. Other key features include:

• All New Aluminium chassis
• Designed and improved suspension kinematics
• Tube In Tube design for easy cable installation
• All new Geometry
• Optimised sizing/fit - Small to XXL
• Sram UDH
• Now fits a 750ml water bottle inside the main front triangle!

The new Mega frame is optimised around the rider and weight distribution. The new geometry features dynamic saddle offset. Seat angles are optimised for each frame size and the seat tube itself is designed to take a longer dropper post if required.

Frame: Nukeproof Mega 290 Alloy, 160mm Travel, custom triple butted hydro-formed tube set, internal dropper seatpost cable routing, Enduro Bearings, Threaded 73mm BB, Boost 148mm rear axle spacing, 3D contoured frame protection

Fork: RockShox Yari, Motion Control RC damper, 170mm, 42mm Offset, BOOST, Debonair, Diffusion Black

Shock: RockShox Super Deluxe Select R, Custom ML tune, 230x62.5mm, Bearing End (We recommend most riders use 0/1 bottomless tokens but the shock comes with 2 tokens fitted, so you have an extra if needed.)

Front Wheel: Sun-Ringle Duroc SD37 Comp 29", 15x110mm

Rear Wheel: Sun-Ringle Duroc SD37 Comp 29", Shimano Driver, 148x12mm

Tyres Front: Michelin Wild Enduro 29" x 2.4, MAGI-X TS TLR, Rear: Michelin Wild Enduro 29” x 2.4, GUM-X TS TLR

Crankset: Shimano Deore M6100 12 Speed Crank, 170mm, 30T, 52mm Chainline

Shifter: Shimano Deore M6100-IR, 12-speed Rapidfire Plus, I-Spec EV

Rear Deraileur: Shimano Deore M6100, SGS 12-Speed, Shadow Plus

Chain: Shimano Deore M6100 12-Speed

Cassette: Shimano Deore M6100 12-Speed (HYPERGLIDE+), 10-51T

Chain Guide: MRP 1x CS, 28-34T, ISCG-05, black

Brakes: Shimano Deore M6120 4 pot brake, Resin Pads

Front Rotor: Shimano SM-RT66, 203mm

Rear Rotor: Shimano SM-RT66, 180mm

Handlebars: Nukeproof Neutron 25mm Rise, Width - S780mm, M780mm, L800mm, XL800mm)

Grips: Nukeproof Sam Hill Signature

Stem: Nukeproof Neutron AM, 45mm, black

Saddle: Nukeproof Horizon Enduro, Black

Seatpost: Brand X Ascend internal, S:125mm drop; M:150mm drop; L/XL/XXL:170mm drop

Headset: Nukeproof, 44-56 IITS

Bearings: Enduro Bearings

Weight: 15.5Kgs/34.2bs (Tubeless)
