Kinesis RISE PRO E-Trail Hardtail Mountain Bike (2021)
Introducing the all new Nukeproof Reactor: an old school name with a very new school look. Although it takes its name from the original 1996 Nukeproof Reactor trail frame, a lot has changed in the last 23 years as it runs an all new trail focused platform.
From concept through to design, the Kinematics, the geometry and specification; the Reactor is designed from the ground up to be the ultimate aggressive trail bike. It is at home on technical climbs, but happiest when thrashing the most technical trails you can point it at.
The Alloy Reactor features a custom triple butted hydro-formed tube set and carbon seat stays, which help reduce the overall weight of the frameset. Critically this reduces the unsprung weight; making the suspension as active as possible.
The Reactor is available for 27.5” or 29” wheel sizes. These are two totally different, compromise free frames that were designed and developed at the same time. Each frame is simply tailored around each wheel size.
Speed or play: which do you value more? The manoeuvrability of 27.5” or the raw speed of a 29”?
All Reactor frames feature a “flip chip” to adjust the geometry from “Trail” to “Rail mode”.
Trail – As the name suggests, this setting is best suited for trail riding. It is for riders who get as much enjoyment from the climb as the descents.
Rail – The Rail setting turns the Reactor into a corner shredder, dropping the bottom bracket 6mm and slackening the head angle by half a degree. It is there to maximise the descending capabilities.
To ensure the bike could climb as well as it descends, we designed the 4 bar horst linkage to have higher levels of anti-squat for climbing gears but lower levels when you drop down the cassette. This means that the bike can behave itself on the climbs but when you get it up to speed, it turns into a trail hooligan. The combination of low anti-squat and progressive rate give ultimate small bump compliance (removes rough trail and root chatter) with good mid stroke support for cornering/pumping and end stroke progression for aggressive riding. Balanced anti-rise figures allow the Reactor some squat when braking hard, maintaining rider position and providing a good amount of pressure through the tyre to ensure traction. The Reactor is designed to reward the rider and ensure you get that stoke factor in on any ride.
|FRAME||Nukeproof Reactor 275 Carbon, 140mm Travel, UD woven Carbon Fibre frame, internal cable routing, ISCG 05 mounts, Enduro bearings, Threaded 73mm BB, Boost 148mm rear axle spacing, 3D contoured rubber frame protection|
|FORK||Fox 36 Float, Performance Elite Series, Grip 2 Damper, 150mm, 44mm Offset, BOOST, Black (SHORT ID: D6GC)|
|SHOCK||Fox Float DPX2, Performance Elite Series, 3 Position, LV EVOL, Custom CL, DRL, Rezi A F F tune, 210x55mm, Bearing End, 1x 0.3 spacer fitted. (SHORT ID: D6TC)|
|FRONT WHEEL||DT Swiss M1900 SPLINE 27.5", 6 Bolt, 110x15mm|
|REAR WHEEL||DT Swiss M1900 SPLINE 27.5", 6 Bolt, Shimano Microspline Driver, 148x12mm|
|TYRES||Front: Maxxis Assegai 27.5”x2.5 WT 3C MaxxTerra/EXO+/TR, Rear: Maxxis Dissector 27.5”x2.4 WT 3C MaxxTerra/EXO+/TR|
|CRANKSET||Shimano SLX M7100 12-Speed, Hollowtech 2, 170mm, 32T, 52mm Chainline|
|SHIFTER||Shimano SLX M7100-IR, 12-speed Rapidfire Plus, I-Spec EV|
|REAR DERAILEUR||Shimano SLX M7100, SGS 12-Speed, Shadow Plus|
|CHAIN||Shimano SLX M7100 HG 12-speed Inc Quicklink|
|CASSETTE||Shimano SLX M7100-12, 12-Speed (HYPERGLIDE+), 10-51T|
|BRAKES||Shimano SLX M7120, 4 Pot Brake, Metallic Pads with Fins|
|FRONT ROTOR||Shimano SM-RT66, 203mm|
|REAR ROTOR||Shimano SM-RT66, 180mm|
|HANDLEBARS||Nukeproof Horizon V2 25mm Rise, Width - S780mm, M780mm, L800mm, XL800mm)|
|STEM||Nukeproof Horizon, 50mm, Black|
|SADDLE||Nukeproof Horizon SL, Black|
|SEATPOST||Brand X Ascend internal w Shimano SL-MT500-IL Remote lever, M:150mm drop; L/XL:170mm drop|
|HEADSET||Nukeproof, 44-56 IITS|
|GRIPS||Nukeproof Sam Hill Signature|
|WEIGHT: (SIZE MEDIUM)||14.5Kgs/31.9lbs (Tubeless)|
